IDEAL Thermo-Shrink 3/32"x4' Heavy-Wall Heat Shrink, Model 46-602*

IDEAL Thermo-Shrink 3/32"x4' Heavy-Wall Heat Shrink, Model 46-602*

Description

Ideal Industries Thin-Wall Thermo-Shrink heat shrinkable tubing. Roll of 4' long 3/32" diameter. Suitable for cable range 14 AWG - 12 AWG

Benefits

  • Polyolefin material electrically insulates and protects in-line components, disconnect terminals and splices with its high strength and excellent resilience
  • Use to bundle wires for very flexible light-duty harnesses
  • Highly flame-retardant and flexible; resistant to common fluids and solvents
  • Meets UL 486D 125°C VW-1 600V; Material: No PBB’s, PBBE’s, conforms to ROHS
  • 2:1 shrink ratio; Minimum shrink temperature: 70°C; Operating temperature: -55°C to +125°C
  • RoHS compliant
  • UV resistant

Technical Information

Normal Size: 3/32"
Expanded I.D. (Min.) 0.122"/3.1mm
Nominal Recovered I.D. (Max.): 0.047"/1.2mm
Recovered Wall Thickness +/- 10%: 0.017"/0.44mm
Max. Cable Range: 12 AWG
Min. Cable Range: 12 AWG
Heat Shrink Length: 4 ft.
Heat Shrink Type: Thin-Wall
$5.38

Original: $15.37

-65%
IDEAL Thermo-Shrink 3/32"x4' Heavy-Wall Heat Shrink, Model 46-602*—

$15.37

$5.38
